Python Kinematics Practice: Building Forward Kinematics from Scratch
Published: 2026-04-11 | Author: Smartotics Learning Journey | Reading Time: 10 min
Figure 1: Python Forward Kinematics: Workspace visualization with code snippet
Quick Summary
Today we write Python code that computes forward kinematics from scratch — no robotics libraries, just NumPy. You’ll build a rotation matrix function, a homogeneous transform function, and a 2-DOF arm forward kinematics solver. By the end, you’ll have a working kinematics library you can extend to 3-DOF and 6-DOF arms.
Setup: What You Need
pip install numpy matplotlib
That’s it. NumPy for matrix math, Matplotlib for visualization.
Step 1: Build Rotation Matrices
These are the three basic rotations around X, Y, and Z axes:
import numpy as np
def rot_x(theta): """Rotation matrix about X axis by theta radians""" c, s = np.cos(theta), np.sin(theta) return np.array([ [1, 0, 0], [0, c, -s], [0, s, c] ])
def rot_y(theta): """Rotation matrix about Y axis by theta radians""" c, s = np.cos(theta), np.sin(theta) return np.array([ [ c, 0, s], [ 0, 1, 0], [-s, 0, c] ])
def rot_z(theta): """Rotation matrix about Z axis by theta radians""" c, s = np.cos(theta), np.sin(theta) return np.array([ [c, -s, 0], [s, c, 0], [0, 0, 1] ])
Test: rotate point [1, 0, 0] by 90 degrees around Z
p = np.array([1.0, 0.0, 0.0]) R_90 = rot_z(np.pi / 2) p_rotated = R_90 @ p print(f”Rotated [1, 0, 0] by 90 deg around Z: {p_rotated}“)
Expected: [0, 1, 0]
@ means matrix multiplication
In Python/NumPy, the @ operator is matrix multiplication. Don’t use * — that does element-wise multiplication. A @ B is the same as np.matmul(A, B).
Step 2: Build Homogeneous Transform
def homogeneous_transform(R, d): """ Create 4x4 homogeneous transform from 3x3 rotation R and 3x1 translation d.
T = [ R | d ]
[ 0 | 1 ]
"""
T = np.eye(4)
T[:3, :3] = R
T[:3, 3] = d
return T
Example: rotate 30 degrees around Z, then translate [0.5, 0, 0]
R = rot_z(np.radians(30)) d = np.array([0.5, 0.0, 0.0]) T = homogeneous_transform(R, d) print(“Transform matrix:”) print(T.round(3))
We can extract position and orientation back from any transform:
def extract_pose(T): """Extract (position, rotation_matrix) from 4x4 transform""" position = T[:3, 3] rotation = T[:3, :3] return position, rotation
def invert_transform(T): """Inverse of homogeneous transform (fast: transpose instead of inversion)""" T_inv = np.eye(4) R = T[:3, :3] d = T[:3, 3] T_inv[:3, :3] = R.T T_inv[:3, 3] = -R.T @ d return T_inv
Step 3: 2-DOF Planar Arm Forward Kinematics
Now combine everything. The 2-joint planar arm has two links with lengths L1 and L2:
def fk_2dof(q1, q2, L1, L2): """ Forward kinematics for 2-DOF planar arm.
Args:
q1, q2: joint angles in radians
L1, L2: link lengths in meters
Returns:
x, y: end-effector position
"""
# Transform from base to joint 1
T_0_1 = homogeneous_transform(rot_z(q1), np.array([L1 * np.cos(q1), L1 * np.sin(q1), 0]))
# Transform from joint 1 to end-effector
T_1_2 = homogeneous_transform(rot_z(q2), np.array([L2 * np.cos(q2), L2 * np.sin(q2), 0]))
# Chain: base to end-effector
T_0_2 = T_0_1 @ T_1_2
# Extract position
x, y, z = T_0_2[:3, 3]
return x, y
Test: q1=30 deg, q2=45 deg, L1=0.5m, L2=0.3m
x, y = fk_2dof(np.radians(30), np.radians(45), 0.5, 0.3) print(f”End-effector position: x={x:.4f}m, y={y:.4f}m”)
Expected: x ≈ 0.642m, y ≈ 0.462m
Step 4: Visualize the Arm
Seeing the robot move makes everything click:
def plot_2dof_arm(q1, q2, L1, L2): """Visualize the 2-DOF planar arm using matplotlib""" import matplotlib.pyplot as plt
# Compute joint positions
origin = np.array([0.0, 0.0])
joint1 = np.array([L1 * np.cos(q1), L1 * np.sin(q1)])
ee_x, ee_y = fk_2dof(q1, q2, L1, L2)
end_effector = np.array([ee_x, ee_y])
# Plot
fig, ax = plt.subplots(1, 1, figsize=(8, 8))
# Draw links
ax.plot([origin[0], joint1[0]], [origin[1], joint1[1]], 'b-', linewidth=3, label='Link 1')
ax.plot([joint1[0], end_effector[0]], [joint1[1], end_effector[1]], 'r-', linewidth=3, label='Link 2')
# Draw joints
ax.plot(*origin, 'ko', markersize=10, label='Base')
ax.plot(*joint1, 'go', markersize=8, label='Joint 1 (Elbow)')
ax.plot(*end_effector, 'ro', markersize=8, label='End-Effector')
ax.set_xlim(-1.5, 1.5)
ax.set_ylim(-1.5, 1.5)
ax.set_aspect('equal')
ax.axhline(y=0, color='gray', linewidth=0.5)
ax.axvline(x=0, color='gray', linewidth=0.5)
ax.grid(True, alpha=0.3)
ax.legend()
ax.set_title(f'2-DOF Planar Arm: q1={np.degrees(q1):.0f}, q2={np.degrees(q2):.0f}')
plt.show()
Visualize
q1 = np.radians(30) q2 = np.radians(45) plot_2dof_arm(q1, q2, 0.5, 0.3)
Step 5: General D-H Forward Kinematics
Instead of hardcoding for 2-DOF, let’s use the D-H parameters properly. This function works for any serial robot:
def dh_transform(theta, d, a, alpha): """ Standard Denavit-Hartenberg transform.
Args:
theta: joint angle (radians) - variable for revolute joints
d: link offset - variable for prismatic joints
a: link length
alpha: link twist
Returns:
4x4 homogeneous transformation matrix
"""
ct, st = np.cos(theta), np.sin(theta)
ca, sa = np.cos(alpha), np.sin(alpha)
return np.array([
[ct, -st*ca, st*sa, a*ct],
[st, ct*ca, -ct*sa, a*st],
[0, sa, ca, d ],
[0, 0, 0, 1 ]
])
def fk_serial(dh_params, joint_angles): """ Forward kinematics for any serial chain robot.
Args:
dh_params: list of [a, alpha, d] for each joint (theta varies)
joint_angles: list of theta values for each joint
Returns:
4x4 transform from base to end-effector
"""
T = np.eye(4)
for i, (a, alpha, d) in enumerate(dh_params):
T = T @ dh_transform(joint_angles[i], d, a, alpha)
return T
Example: 2-DOF planar arm using D-H
dh_2dof = [ [0.5, 0, 0], # Joint 1: a=0.5, alpha=0, d=0 [0.3, 0, 0], # Joint 2: a=0.3, alpha=0, d=0 ] T_ee = fk_serial(dh_2dof, [np.radians(30), np.radians(45)]) print(f”End-effector position: [{T_ee[0,3]:.4f}, {T_ee[1,3]:.4f}, {T_ee[2,3]:.4f}]“)
From Here to 6-DOF
The fk_serial() function above works for any number of joints. For a 6-axis industrial robot, just provide 6 D-H parameter sets and 6 joint angles. The math is exactly the same — only the input data changes.
Exercises: Try These
- Vary the angles: Try q1=0, q2=0 (fully extended) and q1=90, q2=-90 (folded). Verify the positions match your mental model.
- Add a third joint: Extend the DH parameters list to 3 joints. Add a vertical offset (d != 0) to the third joint.
- Workspace analysis: Sweep q1 and q2 from -180 to 180 degrees and plot all reachable (x, y) positions. The shape you see is the robot’s workspace.
Exercise 3: Plot workspace
import matplotlib.pyplot.pyplot as plt
workspace_x, workspace_y = [], [] for q1_deg in range(-180, 181, 5): for q2_deg in range(-180, 181, 5): x, y = fk_2dof(np.radians(q1_deg), np.radians(q2_deg), 0.5, 0.3) workspace_x.append(x) workspace_y.append(y)
plt.figure(figsize=(8, 8)) plt.scatter(workspace_x, workspace_y, s=1, alpha=0.5) plt.gca().set_aspect(‘equal’) plt.title(‘2-DOF Planar Arm Workspace’) plt.xlabel(‘X (m)’) plt.ylabel(‘Y (m)’) plt.grid(True, alpha=0.3) plt.show()
FAQ
Q: I don’t have Python or NumPy set up. What do I do?
Install Python from python.org, then run pip install numpy matplotlib. If you need a free environment, use Google Colab — it has NumPy pre-installed and runs in your browser.
Q: Why write from scratch instead of using a robotics library?
You write it once to understand. Then you use a library for production. Understanding is non-negotiable — otherwise you’re just a library user, not an engineer.
Q: How do I extend this to 3D?
Add Z rotations to each DH parameter row. Set alpha to non-zero values and d to non-zero values. The fk_serial() function above already handles 3D — you just need 3D D-H parameters.
Key Takeaways
